Cantilever Beam Floodlight Pole with 1 Floodlight
Cantilever Beam floodlight pole carrying 1 floodlight, on a hot-dip galvanised steel pole supplied with the base plate, the anchor bolts and the foundation drawing.
- Section: Round conical (tapered round) steel pole
- Bracket type: Fixed bracket
- Bracket: Cantilever Beam bracket carrying 1 floodlight
- Standard heights: 6 m to 12 m; other heights produced to the project drawing
- Material: Steel Q235, Q235B or Q345
- Finish: Hot-dip galvanised as standard
- Supplied with: Base plate, door, cable entry, anchor bolts and foundation drawing
- Mounting: Bracket welded at the required height and drilled ready for the floodlights
Cantilever Beam floodlight poles light car parks, aprons, sports courts and industrial yards where the luminaires have to be aimed rather than spread along a road. This pole carries a Cantilever Beam bracket with 1 floodlight on a single galvanised mast.
Delivered hot-dip galvanised with the base plate welded on, the pole door for wiring access and the anchor bolts, together with the foundation drawing.
At a glance
| Section | Round conical (tapered round) steel pole |
| Bracket type | Fixed bracket |
| Bracket | Cantilever Beam bracket carrying 1 floodlight |
| Standard heights | 6 m to 12 m; other heights produced to the project drawing |
| Material | Steel Q235, Q235B or Q345 |
| Finish | Hot-dip galvanised as standard |
| Supplied with | Base plate, door, cable entry, anchor bolts and foundation drawing |
| Mounting | Bracket welded at the required height and drilled ready for the floodlights |
Cantilever Beam Floodlight Pole with 1 Floodlight — technical parameters
| Height H | Wall thickness S (mm) | Top Ø D1 (mm) | Bottom Ø D2 (mm) | Base plate F1 (mm) | Weight F2 (kg) |
|---|---|---|---|---|---|
| 6 m | 2.5 / 3 | 60–76 | 135 / 140 | 280×280×12 | 55 |
| 7 m | 2.75 / 3 | 60–76 | 150 | 280×280×12 | 81 |
| 8 m | 3 | 60–76 | 150 / 160 | 280×280×12 | 100 |
| 9 m | 3.25 / 3.50 | 60–76 | 175 / 180 | 300×300×12 | 118 |
| 10 m | 3.5 / 3.75 | 60–75 | 180 / 190 | 350×350×12 | 146 |
| 11 m | 3.5 / 3.75 / 4 | 60–70 / 80 | 180 / 200 / 210 | 350×350×16 | 165 |
| 12 m | 3.75 / 4 | 60–70 / 80 | 200 / 210 | 350×350×16 | 190 |
Tell us the pole height, the number of floodlights, the mounting height and the wind zone and we will confirm the section, the wall thickness, the base plate and the anchor bolts for your project.
