All-in-One Solar Light
Built-in solar panel, LiFePO4 battery, LED light source and intelligent controller in one integrated unit. No wiring and no electricity bill.
33 products
Warranty: this range is offered with the supplier factory’s 5-year warranty. Which components it covers, the exclusions and the claim process are confirmed in the quotation — we do not extend the term to parts or conditions it does not cover.
All-in-One Solar Light
Built-in solar panel, LiFePO4 battery, LED light source and intelligent controller in one integrated unit. No wiring and no electricity bill — engineered for roads, residential communities and off-grid areas.
One Unit. Everything Integrated.
The HC series integrates the solar panel, lithium battery, LED light source and controller into one compact aluminium housing. Because every unit is pre-assembled and factory tested before shipment, on-site work is limited to mounting the unit on the pole — no trenching, no cable runs and no connection to the grid.
This makes it the most cost-effective option for projects where installing power cables is difficult, slow or expensive.
- Built-in solar panel and LiFePO4 battery — no external wiring
- Modular pluggable LED design for easy service and upgrade
- Intelligent dimming with light, time and motion control
- Aluminium alloy full-structure waterproof housing
Key Features
Integrated Design
Solar panel, LiFePO4 battery, controller and LED in a single die-cast aluminium housing.
IP65 Waterproof
Full aluminium alloy structure with IP65-rated housing, built for coastal and rainy regions.
LiFePO4 Battery
Long-cycle lithium battery, stable at high ambient temperature.
Intelligent Dimming
Dusk-to-dawn operation with motion-activated dimming and timer modes.
Tool-Free Installation
Pre-assembled and factory tested. Mount on the pole, tighten the bracket, done.
Remote Control Option
Lighting modes and dimming profiles set at the factory or adjusted by remote control.
LED Face & Solar Panel Face
The LED array and the monocrystalline solar panel sit on opposite faces of the same housing, so the LED is protected from above while the panel stays clear of shadow. The mounting bracket clamps directly onto the pole — no separate bracket assembly required.
From 20W to 150W — One Housing Family
Choose the wattage by road width, pole height and required illumination level. The table below is a quick selection guide — our engineers will confirm the exact configuration for your project.
| Power | Solar Panel | Battery | Mounting Height | Typical Use |
|---|---|---|---|---|
| 20W / 30W | 45W | 3.2V 60Ah | 4–6 m | Footpaths, gardens, small lanes |
| 30W / 40W | 50W | 3.2V 75Ah | 5–8 m | Residential roads |
| 40W | 70W | 3.2V 105Ah | 6–8 m | Community roads |
| 50W | 80W | 3.2V 120Ah | 7–9 m | Main roads |
| 60W | 90W | 3.2V 150Ah | 7–10 m | Main roads, industrial parks |
| 80W / 100W | 115W | 12.8V 60Ah | 8–11 m | Highways, arterial roads |
| 120W / 150W | 200W | 25.6V 60Ah | 12–16 m | Expressways, large interchanges |
Full Specifications
The HC range is available from 20W to 150W. All models share the same integrated architecture and IP65 aluminium housing. LED chip options 3030 / 5050 / 7070 are available — the luminous flux column lists the output for each, in that order.
Table 1 – 20W to 60W (3.2V battery)
| Model | HC-20W/30W | HC-30W/40W | HC-40W | HC-50W | HC-60W |
|---|---|---|---|---|---|
| Power | 20W / 30W | 30W / 40W | 40W | 50W | 60W |
| Solar Panel | 45W | 50W | 70W | 80W | 90W |
| Battery | 3.2V 60Ah | 3.2V 75Ah | 3.2V 105Ah | 3.2V 120Ah | 3.2V 150Ah |
| Luminous Flux 3030 / 5050 / 7070 | 2800–4200 / 3400–5100 / 3800–5700 lm | 4200–5600 / 5100–6800 / 5700–7600 lm | 5600 / 6800 / 7600 lm | 7000 / 8500 / 9500 lm | 8400 / 10200 / 11400 lm |
| PV Panel Size | 820×272 mm | 1070×272 mm | 1070×340 mm | 1070×398 mm | 1170×398 mm |
| Light Size | 900×300 mm | 1130×300 mm | 1130×370 mm | 1130×425 mm | 1230×425 mm |
| Mounting | Tripod + support bar | ||||
| Mounting Height | 4–6 m | 5–8 m | 6–8 m | 7–9 m | 7–10 m |
Table 2 – 30W to 80W (12.8V battery)
| Model | HC-30W/40W-L | HC-40W/50W | HC-50W/60W | HC-60W | HC-70W/80W |
|---|---|---|---|---|---|
| Power | 30W / 40W | 40W / 50W | 50W / 60W | 60W | 70W / 80W |
| Solar Panel | 50W | 70W | 80W | 90W | 100W |
| Battery | 12.8V 24Ah | 12.8V 30Ah | 12.8V 36Ah | 12.8V 45Ah | 12.8V 45Ah |
| Luminous Flux 3030 / 5050 / 7070 | 4200–5600 / 5100–6800 / 5700–7600 lm | 5600–7000 / 6800–8500 / 7600–9500 lm | 7000–8400 / 8500–10200 / 9500–11400 lm | 8400 / 10200 / 11400 lm | 9800–11200 / 11900–13600 / 13300–15200 lm |
| PV Panel Size | 1070×272 mm | 1070×340 mm | 1070×398 mm | 1070×398 mm | 1298×398 mm |
| Light Size | 1130×300 mm | 1130×370 mm | 1130×425 mm | 1130×425 mm | 1350×425 mm |
| Mounting | Tripod + support bar | ||||
| Mounting Height | 5–8 m | 6–8 m | 7–9 m | 7–10 m | 7–10 m |
Table 3 – 80W to 150W (12.8V / 25.6V battery · vertical sleeve mounting)
| Model | HC-80W/100W | HC-90W/100W | HC-100W/120W | HC-120W/150W |
|---|---|---|---|---|
| Power | 80W / 100W | 90W / 100W | 100W / 120W | 120W / 150W |
| Solar Panel | 115W | 135W | 165W | 200W |
| Battery | 12.8V 60Ah | 25.6V 36Ah | 25.6V 45Ah | 25.6V 60Ah |
| Luminous Flux 3030 / 5050 / 7070 | 11200–14000 / 13600–17000 / 15200–19000 lm | 12600–14000 / 15300–17000 / 17100–19000 lm | 14000–16800 / 17000–20400 / 19000–22800 lm | 16800–21000 / 20400–25500 / 22800–28500 lm |
| PV Panel Size | 1460×398 mm | 1330×500 mm | 1420×580 mm | 1480×666 mm |
| Light Size | 1530×425 mm | 1360×530 mm | 1450×610 mm | 1520×700 mm |
| Mounting | Tripod + support bar | Vertical sleeve | Vertical sleeve | Vertical sleeve |
| Mounting Height | 8–11 m | 9–12 m | 10–14 m | 12–16 m |
Colour Temperature: 4000K / 5000K / 6000K · Control Mode: light control, time control, motion sensor · Waterproof Grade: IP65 · Warranty: 5 years
Specifications are subject to change without notice. Custom wattage, colour temperature, pole height and battery capacity are available on request.
Product Details
Close-up views of the LED module, sensor, solar panel and mounting hardware.
Where It Works Best
Compact all-in-one units suit projects where cable trenching is costly or impossible — rural roads, residential communities, parks, car parks, industrial estates and off-grid areas. For wide roads and mounting heights above 9 m, our split solar street light range is usually the better fit.
How to Choose the Right Model
- ✓Match wattage to road width and required lux level
- ✓Size the battery for the required backup days during cloudy or rainy periods
- ✓Choose pole height according to installation spacing and lighting uniformity
- ✓Confirm the mounting method and whether a pole needs to be supplied
Frequently Asked Questions
Can it be installed without cabling?
Yes. All-in-one units are self-contained and require no trenching or grid connection.
Is a remote control available?
Optional. Lighting modes and dimming profiles can be set at the factory or adjusted by remote control depending on the model.
What is the MOQ and lead time?
MOQ depends on the configuration; project orders are welcome. Lead time is confirmed at quotation stage.
Delivered on Real Projects
All-in-one solar lights supplied and installed on road, community and rural lighting projects in the Philippines and other Southeast Asian markets.
Sourced, Inspected, Delivered
We work directly with qualified solar lighting factories and carry out independent inspection before shipment — LED module function test, battery capacity check, waterproofing check and packing verification. You receive a photo pack of the actual goods before they leave China.
Quality checks before shipment
- Light output and charging / discharging test
- Waterproof and appearance inspection
- Packing check suitable for sea freight
- Third-party inspection available on request
- Photo pack of the actual shipment supplied to you
Get a Quotation for Your Project
Tell us your pole height, road width and required lighting hours. We will recommend the right wattage and send a quotation within one working day.
