HC All-in-One Solar Street Light 80 W to 150 W
All-in-One Solar Street Light

HC All-in-One Solar Street Light — 80 W to 150 W

12.8 V / 25.6 V battery · mounting height 8–16 m · vertical sleeve mount

  • Range: HC-80W/100W to HC-120W/150W
  • Battery: 12.8 V 60 Ah – 25.6 V 60 Ah
  • Ingress protection: IP65
  • Mounting: Tripod + support bar (80W/100W); vertical sleeve (100W/120W and 120W/150W)
  • Mounting height: 8–16 m
Request a QuoteChat on WhatsApp

The 80 W to 150 W models step up to a 25.6 V battery on the larger sizes and mount through a vertical sleeve rather than a tripod, for highways, arterial roads and large interchanges at mounting heights from 8 m to 16 m.

Choose the wattage by road width, pole height and required illumination level; the table below is a quick selection guide and the exact configuration is confirmed at quotation stage.

At a glance

RangeHC-80W/100W to HC-120W/150W
Battery12.8 V 60 Ah – 25.6 V 60 Ah
Ingress protectionIP65
MountingTripod + support bar (80W/100W); vertical sleeve (100W/120W and 120W/150W)
Mounting height8–16 m

HC All-in-One Solar Street Light 80 W to 150 W — technical parameters

ModelHC-80W/100WHC-90W/100WHC-100W/120WHC-120W/150W
Power80W / 100W90W / 100W100W / 120W120W / 150W
Solar Panel115W135W165W200W
Battery12.8V 60Ah25.6V 36Ah25.6V 45Ah25.6V 60Ah
Luminous Flux 3030/5050/707011200–14000 / 13600–17000 / 15200–19000 lm12600–14000 / 15300–17000 / 17100–19000 lm14000–16800 / 17000–20400 / 19000–22800 lm16800–21000 / 20400–25500 / 22800–28500 lm
PV Panel Size1460×398 mm1330×500 mm1420×580 mm1480×666 mm
Light Size1530×425 mm1360×530 mm1450×610 mm1520×700 mm
MountingTripod + support barVertical sleeveVertical sleeveVertical sleeve
Mounting Height8–11 m9–12 m10–14 m12–16 m

Parameters are the supplier's published figures for the models listed. Tell us your road width, pole height and required lighting hours and we will confirm the exact configuration for your project.
